20KW 60KW 77KW for Solar Energy Storage Lithium Stackable Vertical Battery Pack LiFePO4 Batteries
- RANKTOP
- ZhongShan
- 5-15 Days
- 5000/Week
204.8V 100AH Vertically Stacked Energy Storage Battery Pack
Model:DQ2910A20-01
Battery Type: LiFePO4
Nominal Voltage: 204.8V
Nominal Capacity: 100Ah
Charging Cut-off Voltage: 230.4V
Discharging Cut-off Voltage: 179.2V
Max. Cont. Charging/Discharging Current: 100A
Max. Instantaneous Charge/Discharge Current: 100A
Cycle Life: ≥6000
Product Size: 610.5*549*1020mm
Weight: 242kg
Warranty: 5 years
409.6V 100AH Vertically Stacked Energy Storage Battery Pack
Model：DQ2910B40-01
Battery Type: LiFePO4
Nominal Voltage: 409.6V
Nominal Capacity: 100Ah
Charging Cut-off Voltage: 460.8V
Discharging Cut-off Voltage: 358.4V
Max. Cont. Charging/Discharging Current: 100A
Max. Instantaneous Charge/Discharge Current: 100A
Cycle Life: ≥6000
Product Size: 610.5*549*1604mm
Weight: 443kg
Warranty: 5 years
614.4V 100AH Vertically Stacked Energy Storage Battery Pack
Model:DQ2910C60-01
Battery Type: LiFePO4
Nominal Voltage: 614.4V
Nominal Capacity: 100Ah
Charging Cut-off Voltage: 691.2V
Discharging Cut-off Voltage: 537.6V
Max. Cont. Charging/Discharging Current: 100A
Max. Instantaneous Charge/Discharge Current: 100A
Cycle Life: ≥6000
Product Size: 610.5*549*2188mm
Weight: 644kg
Warranty: 5 years
768V 100AH Vertically Stacked Energy Storage Battery Pack
Model：DQ2910D77-01
Battery Type: LiFePO4
Nominal Voltage: 768V
Nominal Capacity: 100Ah
Charging Cut-off Voltage:865V
Discharging Cut-off Voltage: 672V
Max. Cont. Charging/Discharging Current: 100A
Max. Instantaneous Charge/Discharge Current: 100A
Cycle Life: ≥6000
Product Size: 1099*610.5*1454mm
Weight: 813kg
Warranty: 5 years
Product Advantage
20kw,40kw,60kw,77kw Vertically Stacked Energy Storage Battery Pack
Ranktop DQ2910 series is an advanced system. The system consists of rack-mounted battery modules, each with a capacity of 5.12 kWh. Multiple modules can be connected in series and parallel to achieve the required storage capacity, and its modular and scalable architecture provides flexible capacities from 20.48kWh to 76.8kWh. Standardized 3U chassis design for easy installation and maintenance.modular battery energy storage system，Home Battery Solar Energy Storage，energy storage battery containerCustomized Home solar energy storage System，
Key features of this battery pack include a service life of more than 10 years, integrated battery management system protection, an operating temperature range of -20°C to 55°C, and a depth of discharge of up to 90% for excellent energy. The intrinsically safe LifePO4 chemistry also makes the system reliable and environmentally friendly. Advanced monitoring and control capabilities to optimize system performance and longevity.energy storage battery container，modular battery energy storage system，Home Battery Solar Energy Storage，energy storage battery containerCustomized Home solar energy storage System.modular battery energy storage system，Home Battery Solar Energy Storage，energy storage battery containerCustomized Home solar energy storage System，Home Battery Solar Energy Storage.
