High Voltage 10kwh 20kwh 30kwh 40kwh 10kw Solar Flat Layer Stacked Energy Storage Battery System
- RANKTOP
- ZhongShan
- 5-15 Days
- 5000/Week
10KW/10KWH Flat Layer Stacked Energy Storage
Model:DQ1912A10K-01
Rated Power: 10KW
LiFePO4 Battery: 200Ah/51.2V
AC Output Voltage: 230VAC
AC Output Frequency: 50/60Hz
AC Input Voltage Range: 170-280VAC
AC Input Frequency: 50/60Hz
Maximum AC innut current/charging current: 60A/150A
Maximum PV Voltage: 500VDC
MPPT Voltage Range: 120-450VDC
PV Charge Current: 150A
Temperature For Operation: -20-+50℃
Temperature For Storage: -30 -+70℃
External Dimensions:750*480*510mm
Weight: 126kg
Warranty: 3 years
10KW/20KWH Flat Layer Stacked Energy Storage
Model：DQ1912B10K-01
Rated Power: 10KW
LiFePO4 Battery: 400Ah/51.2V
AC Output Voltage: 230VAC
AC Output Frequency: 50/60Hz
AC Input Voltage Range:170-280VAC
AC Input Frequency: 50/60Hz
Maximum AC innut current/charging current: 60A/150A
Maximum PV Voltage: 500VDC
MPPT Voltage Range: 120-450VDC
PV Charge Current: 150A
Temperature For Operation: -20-+50℃
Temperature For Storage: -30 -+70℃
External Dimensions: 750*480*682mm
Weight: 198kg
Warranty: 3 years
10KW/30KWH Flat Layer Stacked Energy Storage
Model: DQ1912C10K-01
Rated Power: 10KW
LiFePO4 Battery: 600Ah/51.2V
AC Output Voltage: 230VAC
AC Output Frequency: 50/60Hz
AC Input Voltage Range:170-280VAC
AC Input Frequency: 50/60Hz
Maximum AC innut current/charging current: 60A/150A
Maximum PV Voltage: 500VDC
MPPT Voltage Range: 120-450VDC
PV Charge Current: 150A
Temperature For Operation: -20-+50℃
Temperature For Storage: -30 -+70℃
External Dimensions: 750*480*853mm
Weight: 270kg
Warranty: 3 years
10KW/40KWH Flat Layer Stacked Energy Storage
Model：DQ1912D10K-01
Rated Power: 10KW
LiFePO4 Battery:800Ah/51.2V
AC Output Voltage: 230VAC
AC Output Frequency: 50/60Hz
AC Input Voltage Range: 170-280VAC
AC Input Frequency: 50/60Hz
Maximum AC innut current/charging current: 60A/150A
Maximum PV Voltage: 500VDC
MPPT Voltage Range: 120-450VDC
PV Charge Current: 150A
Temperature For Operation: -20-+50℃
Temperature For Storage: -30 -+70℃
External Dimensions: 750*480*1025mm
Weight: 342kg
Warranty: 3 years
Product Advantage
Flat-stacked energy storage system
10KW/10KWH 10KW/20KWH 10KW/30KWH 10KW/40KWH
Product Features:
Pure sine wave inverters; Flat Layer Stacked Energy Storage, power grid side energy storage, Lithium lon Batteries Solar Energy Storage, all-in-one energy storage system , solar energy battery storage system.
Integrated MPPT controller/charger; power grid side energy storage, Lithium lon Batteries Solar Energy Storage, all-in-one energy storage system , solar energy battery storage system.
Settable priority of utility and PV power supply;
Wide PV input voltage.power grid side energy storage, Lithium lon Batteries Solar Energy Storage, all-in-one energy storage system , solar energy battery storage system.
Using LiFePO4 battery, the battery has undergone strict safety testing, and the charging speed is fast, high temperature resistant, green environmental protection, non-toxic and pollution-free
Functions and parameters can be set via the LCD.power grid side energy storage, Lithium lon Batteries Solar Energy Storage, all-in-one energy storage system , solar energy battery storage system.
With battery equalization function to optimize battery performance and extend battery life.
It can be used as backup power supply at night time, or in bad weather days or when grid fails. Also battery can store energy generated throughout off-peak times and then discharge it during peak times, aiding in both peak shifting (by supplying stored enerfy at peak periods) and load shifting (by charging at off-peak period), which can save electricity bills.Contact us today to discuss your energy storage needs!
