Hybrid Solar Power System Solar Energy Storage System 5kw-12kw Hybrid Inverter
- RANKTOP
- ZhongShan
- 5-15 Days
- 5000/Week
5.6KW Hybrid Inverter
Model: THON-5.6KW-01P
Battery Voltage: 51.2VDC
Rated Power: 5600VA/5600W
Rated AC Output Voltage: 230VAC
Rated AC Output Current: 24.3A
Battery Input Voltage Range:40~60VDC
Maximum Battery Current: 125A
Rated AC Input Voltage Range: 170-280VAC
Maximum AC Charging Current: 60A
Maximum PV Input Power:5600W
MPPT Input Voltage Range: 120-450VDC
Maximum PV Input Current: 22A
Maximum PV Charge Current: 100A
IP Grade: IP20
Max. Number Of Parallel: 6 sets
Product Size: 470*318.7*117.5mm
Warranty: 3 Years
8KW Hybrid Inverter
Model: THON-8KW-02P
Battery Voltage: 51.2VDC
Rated Power: 10000VA/8000W
Rated AC Output Voltage: 230VAC
Rated AC Output Current: 35A
Battery Input Voltage Range: 40~60VDC
Maximum Battery Current: 153A
Rated AC Input Voltage Range: 170-280VAC
Maximum AC Charging Current: 150A
Maximum PV Input Power:4500W+4500W
MPPT Input Voltage Range: 90-450VDC
Maximum PV Input Current: 22A+22A
Maximum PV Charge Current: 150A
IP Grade: IP20
Max. Number Of Parallel: 6 sets
Product Size: 576*368.6*133mm
Warranty: 3 Years
10KW Hybrid Inverter
Model: THON-10KW-01P
Battery Voltage: 51.2VDC
Rated Power: 10000VA/10000W
Rated AC Output Voltage: 230VAC
Rated AC Output Current: 50A
Battery Input Voltage Range:40~60VDC
Maximum Battery Current: 260A
Rated AC Input Voltage Range: 170-280VAC
Maximum AC Charging Current: 160A
Maximum PV Input Power: 6000W*2
MPPT Input Voltage Range: 90~500VDC
Maximum PV Input Current: 22A*2
Maximum PV Charge Current: 220A
IP Grade: IP20
Max. Number Of Parallel: 6 sets
Product Size: 651.9*468.6*137mm
Warranty: 3 Years
12KW Hybrid Inverter
Model：THON-12KW-01P
Battery Voltage: 51.2VDC
Rated Power: 12000VA/12000W
Rated AC Output Voltage: 230VAC
Rated AC Output Current: 50A
Battery Input Voltage Range:40~60VDC
Maximum Battery Current: 260A
Rated AC Input Voltage Range: 170-280VAC
Maximum AC Charging Current: 160A
Maximum PV Input Power: 6000W*2
MPPT Input Voltage Range: 90~500VDC
Maximum PV Input Current: 22A*2
Maximum PV Charge Current: 220A
IP Grade: IP20
Max. Number Of Parallel: 6 sets
Product Size: 651.9*468.6*137mm
Warranty: 3 Years
Product Advantage
Ranktop: Leading the Way in Distributed Energy Solutions
Ranktop is a globally recognized leader in distributed energy solutions, dedicated to advancing sustainable energy generation, storage, and consumption, as well as energy digitalization. We specialize in designing, developing, and manufacturing high-quality PV inverters, energy storage systems, and smart energy management solutions, tailored to meet the needs of residential, commercial, and industrial users worldwide. Through our extensive sales channels, we deliver innovative, reliable, and eco-friendly energy products that empower individuals and businesses to achieve energy independence, reduce costs, and contribute to a greener future. Choose Ranktop for cutting-edge technology and sustainable energy solutions that make a difference.
