Solar Hybrid Solar Ongrid Dc Ac Grid Tie Inverter
- RANKTOP
- ZhongShan
- 5-15 Days
- 5000/Week
6.2KW Hybrid Inverter
Model: THON-6.2KW-10P
Battery Voltage: 51.2VDC
Rated Power: 6200W
Rated AC Output Voltage: 230VAC
Rated AC Output Current: 26.9A
Battery Input Voltage Range:40~60VDC
Maximum Battery Current: 135A
Rated AC Input Voltage Range: 170-280VAC, 50/60Hz
Maximum AC Charging Current: 80A
Maximum PV Input Power:6000W
MPPT Input Voltage Range: 120-450VDC
Maximum PV Input Current: 22A
Maximum PV Charge Current: 100A
IP Grade: IP20
Max. Number Of Parallel: 6 sets
Product Size: 446*326*117.5mm
Warranty: 3 Years Net weight: 9.5KG
8KW Hybrid Inverter
Model: THON-8KW-10P
Battery Voltage: 51.2VDC
Rated Power: 8000W
Rated AC Output Voltage: 230VAC
Rated AC Output Current: 35A
Battery Input Voltage Range:40~60VDC
Maximum Battery Current: 183A
Rated AC Input Voltage Range: 170-280VAC, 50Hz
Maximum AC Charging Current: 150A
Maximum PV Input Power:5500W+5500W
MPPT Input Voltage Range: 120-450VDC
Maximum PV Input Current: 22A+22A
Maximum PV Charge Current: 150A
IP Grade: IP20
Max. Number Of Parallel: 6 sets
Product Size: 576*388.5*133mm
Warranty: 3 Years Net weight: 18.10KG
10KW Hybrid Inverter
Model:THON-10KW-10P
Battery Voltage: 51.2VDC
Rated Power: 10000W
Rated AC Output Voltage: 230VAC
Rated AC Output Current: 43.5A
Battery Input Voltage Range:40~60VDC
Maximum Battery Current: 230A
Rated AC Input Voltage Range: 170-280VAC, 50/60Hz
Maximum AC Charging Current: 150A
Maximum PV Input Power: 5500W+5500W
MPPT Input Voltage Range: 120-450VDC
Maximum PV Input Current: 22A+22A
Maximum PV Charge Current: 150A
IP Grade: IP20
Max. Number Of Parallel: 6 sets
Product Size: 576*388.5*133mm
Warranty: 3 Years Net weight: 18.10KG
11KW Hybrid Inverter
Model: THON-11KW-10P
Battery Voltage: 51.2VDC
Rated Power: 11000W
Rated AC Output Voltage: 230VAC
Rated AC Output Current: 48A
Battery Input Voltage Range:40~60VDC
Maximum Battery Current: 250A
Rated AC Input Voltage Range: 170-280VAC, 50Hz
Maximum AC Charging Current: 150A
Maximum PV Input Power: 5500W+5500W
MPPT Input Voltage Range: 120-450VDC
Maximum PV Input Current: 22A+22A
Maximum PV Charge Current: 150A
IP Grade: IP20
Max. Number Of Parallel: 6 sets
Product Size: 576*388.5*133mm
Warranty: 3 Years Net weight: 18.10KG
Product Advantage
THON is a multifunctional off grid solar inverter, integrated with a MPPT solar charge controller, a high
frequency pure sine wave inverter and a UPS function module in one machine, which is perfect for off
grid backup power and self-consumption applications. This inverter can work with or without batteries.
The whole system also need other devices to achieve complete running such as PV modules, generator,
or utility grid. Please consult with us for other possible system architectures depending on your requirements.
The WiFi/GPRS module is a plug-and-play monitoring device to be installed on the inverter. With this device,
users can monitor the status of the PV system from the mobile phone or from the website anytime anywhere.
